These professional units collect 99.97% of all compound dust and precious metal particulate down to sub-Micron levels. Ideal for grinding and polishing applications. Prefilter and state-of-the-art drum-style, cartridge filter ensures return air is absolutely clean, eliminating the need for outside ventilation. See chart below for replacement filters. Built-in collection tray captures your precious metal dust and lets you reclaim it without removing the cartridge filter.
4-Port Model includes 25' of hose and eight clamps.
Backed by a one-year manufacturer’s warranty. CSA and CE approved. Made in Canada.
- Prefilter wraps around drum-style, cartridge filter, prolonging life 2-4 years.
- "Slide & Glide" easy-in/easy-out filter captures particulate down to subMicron particle levels.
- Advanced filtration technology with the highest rating. Unique sub-Micron dust collection filtration down to .03 Microns (Category C: 99.97% dust extraction) recirculates clean air back into the workplace eliminating the need for outside ventilation.
- Built-in collection tray captures precious metal dust for immediate reclaiming.
- Inlet ports can be positioned on top or side of unit.
- Optional On/Off foot switch (854-1369) and silencer which reduces sound 10-15%, attaches without tools (854-1528), are also available.
Item # | 854-1380 |
Model: | 4-Port |
Stations: | 4 |
Electrical: | 120V, 9.2A, 60Hz |
HP: | 1 |
Airflow (CFM): | 800 |
W x D x H (in): | 18" x 34" x 22" |
Height (in): | 23" |
Net Weight: | 120 lbs. (54.4kg) |
Shipping Weight: | 131 lbs. (59.4kg) |
Noise Level: | 58 dBA |
Filter Area (sq.ft): | 60 |
Inlet Diameter (in): | 3" |
Hose Clamps: | 8 |
